Product ID: SL2600
The MOTOTRBO SL2600 is a slim (23 mm) handheld transceiver featuring a haptic virtual keypad, a two-line OLED display, Bluetooth 4.0, Wi-Fi, 256 channels, and support for DMR trunked systems.
Product features:
DMR – analogue and digital operation supporting IP Site Connect and Capacity Plus trunking
Virtual keypad with haptic feedback and a 2-line OLED display that illuminates on touch
Ultra-slim form factor (23 mm) weighing only 190 g
Integrated Bluetooth 4.0 and Wi-Fi for over-the-air software management (OTAP)
Certified IP54 dust and splash resistance and MIL-STD 810 military-grade durability • Product description
The MOTOTRBO SL2600 blends professional push-to-talk performance with a sleek, sophisticated design that complements business attire. Featuring an innovative virtual keypad and a 2-line OLED display, the screen lights up when needed and goes dark when inactive to ensure ultimate discretion. At just 23 mm thick and weighing 190 grams, it fits comfortably into jacket pockets without weighing staff down.
Equipped with Bluetooth 4.0, the SL2600 connects seamlessly with wireless earpieces, enabling hands-free communication while keeping the radio hidden from public view. Integrated Wi-Fi allows IT personnel to execute over-the-air software updates across the entire fleet without managing physical cables. Intelligent Audio automatically balances speaker volume to suppress background noise in dynamic environments.
The SL2600 delivers essential business features including Enhanced Privacy, Transmit Interrupt capability, digital emergency alerts, and Covert Mode. Built to scale as your enterprise grows, it supports single-site conventional operation, multi-site IP Site Connect, and high-capacity Capacity Plus trunking (single and multi-site). Its rugged casing complies with IP54 ingress protection and MIL-STD 810 environmental standards.
The MOTOTRBO SL2600 portable radio is tailored for corporate executives, high-end hospitality staff, event organizers, and commercial venue managers.
Luxury hotels & corporate venues: professional, unobtrusive communication using wireless Bluetooth accessories.
Event centers & airports: instant text messaging and call management via a crisp OLED screen.
Commercial property management: efficient wide-area communication across Capacity Plus trunked networks.
• Specification
Display Type
2-line OLED display with 4-button virtual keypad
Channel Capacity / Zone Capacity
256 / 50
Dimensions (H x W x D)
126 x 55 x 23 mm
Weight with Slim 2300 mAh Li-Ion Battery (PMNN4468)
190 g
Nominal Power Supply
3,7 V
Battery Life (2300 mAh Li-Ion, 5/5/90 duty cycle)
Analogue Mode: 11 h Digital Mode: 13.5 h
Channel Spacing
12,5 kHz / 25 kHz
Frequency Stability
± 1,5 ppm
Digital Vocoder Type
AMBE+2™
Digital Protocol (ETSI standards)
ETSI TS 102 361-1, -2, -3 (DMR Tier II)
Wi-Fi Connectivity
IEEE 802.11b/g/n (WPA, WPA2, WEP)
Bluetooth Module
Version 4.0, Class 2 (10 m range), supported profiles: HSP, SPP, Motorola Fast PTT
Frequency Range
VHF: 136–174 MHz or UHF: 403–480 MHz
RF Output Power
Analogue High Power: 2 W (2 W max for > 470 MHz) Low Power (Analogue / Digital): 0.5 W / 1 W
Conducted / Radiated Emissions (TIA603D)
< 1 GHz: -36 dBm > 1 GHz: -30 dBm
Adjacent Channel Power
12.5 kHz channel: 60 dB 25 kHz channel: 70 dB
Analogue Sensitivity (12 dB SINAD)
0.3 uV (0.22 uV typical)
Digital Sensitivity (5% BER)
0.25 uV (0.19 uV typical)
Intermodulation (TIA603D)
70 dB
Adjacent Channel Selectivity (TIA603A-1T / TIA603D-2T)
12.5 kHz channel: 60 dB / 45 dB 25 kHz channel: 70 dB / 70 dB
Spurious Rejection (TIA603D)
70 dB
Rated Audio
Internal Speaker: 0.5 W
Audio Distortion @ Rated Audio
5% (3% typical)
Hum and Noise
12.5 kHz channel: -40 dB 25 kHz channel: -45 dB
Conducted Spurious Emissions (TIA603D)
-57 dBm
Military Standards MIL-STD 810C/D/E/F/G
Low pressure, low/high temp, thermal shock, solar radiation, rain, humidity, salt fog, dust, sand, vibration, shock
Operating Temperature
-30°C to +60°C (radio) / -10°C to +60°C (with Li-Ion battery)
Storage Temperature
-40°C to +85°C
Ingress Protection (dust and water)
IEC 60529 - IP54
Electrostatic Discharge
IEC 61000-4-2 level 3
