Product ID: R7Ex FKP
The MOTOTRBO R7Ex FKP (Full Keypad) is an ATEX and IECEx certified digital DMR portable radio featuring a full keypad, a 1.7" color display, up to 108 phons speech output, Wi-Fi, Bluetooth 5.2, GNSS location tracking, and IP66/IP68 ingress protection.
Radio is available in two variants: R7Ex(GAS GROUP IIA) or R7Ex(GAS GROUP IIC).
Product features:
DMR – analogue and digital DMR Tier II/III operation with AES256 encryption support and wrong battery alert
Full numeric keypad with 6 programmable buttons and a 1.7" (132 x 90 px) color display
ATEX/IECEx intrinsically safe certified for Gas Zone 1/21, Zone 2/22, Dust IIIC, and Mining M2 hazardous environments
Advanced audio architecture with a 2.5 W speaker, Dual Click volume control with Volume Boost (up to 108 phons), and AI noise suppression
Rugged construction certified to ATEX IP66/IP68 (submersion up to 2 m for 2 hours) and disinfectant-resistant housing • Product description
The MOTOTRBO R7Ex FKP is engineered to provide maximum safety for personnel working in high-risk, potentially explosive environments. Fully certified to ATEX and IECEx standards, it prevents potential ignition risks when flammable gases, vapors, mists, or conductive dusts are present. Its distinctive blue accents allow immediate visual identification of ATEX-safe devices in the field, while a built-in sensor alerts users if a non-ATEX battery is attached.
Equipped with a full numeric keypad and a crisp 1.7" color screen, the R7Ex FKP enables workers to compose freeform text messages, manage contact lists, and utilize Text-to-Speech readout. Designed for extreme noise, its 2.5 W speaker with dynamic Volume Boost delivers speech loudness up to 108 phons. AI-trained noise cancellation filters out heavy machinery, fan, and pump background noise.
The R7Ex FKP undergoes stringent ATEX IP66 and IP68 testing, including thermal endurance and impact conditioning before water submersion tests. Worker protection is reinforced through Fall Alert (Man Down), Lone Worker, a prominent emergency button, and location tracking via GNSS and Bluetooth 5.2. Integrated Wi-Fi supports over-the-air programming (OTAP) and seamless integration with ATEX-certified headsets.
The MOTOTRBO R7Ex FKP portable radio is designed for chemical engineers, maintenance technicians, process operators, and emergency responders in hazardous environments requiring text input and ATEX compliance.
Oil & gas operations & refineries: intrinsically safe communication across Gas Zone 1 / Zone 21 areas with worker tracking.
Chemical & pharmaceutical manufacturing: easy text messaging via full keypad and disinfectant-resistant casing.
Mining & heavy processing: dust-tight performance in conductive dust environments with loudness up to 108 phons.
• Specification
Display Type
1.7" (132 x 90 px) color display, up to 5 lines of text
Keypad
Full numeric keypad (FKP) with 6 programmable buttons
Channel Capacity / Zone Capacity
1000 / 250
Dimensions with Li-Ion IP68 2150 mAh Battery (PMNN4848) – IIA Model / IIC Model
140 x 57 x 40 mm / 140 x 57 x 38 mm
Weight with Li-Ion IP68 2150 mAh Battery & Whip Antenna – IIA Model / IIC Model
460 g / 460 g
Nominal Power Supply
7,4 V
Battery Life (2150 mAh, 5/5/90 duty cycle) – Gas Group IIA
Digital: 19 hrs (23 hrs @ 1 W) / Analogue: 14.5 hrs (20 hrs @ 1 W)
Battery Life (2150 mAh, 5/5/90 duty cycle) – Gas Group IIC
Digital: 23.5 hrs (24.5 hrs @ 1 W) / Analogue: 20.5 hrs (22 hrs @ 1 W)
Channel Spacing
12,5 kHz / 20 kHz / 25 kHz
Frequency Stability (-30°C to +60°C)
± 0,5 ppm
Digital Vocoder Type
AMBE+2™
Digital Protocol (ETSI standards)
ETSI TS 102 361-1, -2, -3, -4 (DMR Tier II, DMR Tier III)
Wi-Fi Connectivity
Wi-Fi 5 / IEEE 802.11a/b/g/n/ac (2.4 GHz, 5 GHz) supporting WPA2, WPA3, and 802.11k/v/r roaming
Bluetooth Module
Version 5.2 (Class 2, 10 m range), supported profiles: HSP, SPP, PAN, GATT
GNSS Receiver
GPS, GLONASS, BeiDou, Galileo (accuracy < 1 m dual constellation, < 5 m single constellation)
Frequency Range
Group IIA: 350–470 MHz or Group IIC: 400–470 MHz
RF Output Power (High / Low)
Group IIA: 4 W / 1 W or Group IIC: 2 W / 1 W (ATEX/IECEx standard limit)
Conducted / Radiated Emissions (ETSI/TIA603E)
< 1 GHz: -36 dBm > 1 GHz: -30 dBm
Adjacent Channel Power
12.5 kHz channel: 60 dB 20/25 kHz channel: 70 dB
Analogue Sensitivity (12 dB SINAD)
0.16 uV (typical) / 0.21 uV (maximum)
Digital Sensitivity (5% BER)
0.14 uV (typical) / 0.18 uV (maximum)
Intermodulation (ETSI / TIA603E)
> 65 dB / > 70 dB
Adjacent Channel Selectivity (ETSI/TIA603A-1T / TIA603E-2T)
12.5 kHz channel: > 60 dB / > 45 dB 20/25 kHz channel: > 70 dB / > 70 dB
Spurious Rejection (ETSI/TIA603E)
> 70 dB
Speech Loudness (ISO532B)
Default Maximum: 101 phons @ 30 cm Programmable Maximum: 108 phons @ 30 cm
Audio Output Power (Rated / Max)
0,5 W / 2,5 W
Audio Distortion @ Rated Audio
≤ 1,5%
Hum and Noise
12.5 kHz channel: -40 dB 20/25 kHz channel: -45 dB
Conducted Spurious Emissions (ETSI/TIA603E)
< 1 GHz: <-57 dBm > 1 GHz: <-47 dBm
ATEX / IECEx Gas Rating
Group IIA: II 2G Ex ib IIA T4 Gb / Ex ib IIA T4 Gb or Group IIC: II 2G Ex ib IIC T4 Gb / Ex ib IIC T4 Gb
ATEX / IECEx Dust Rating
II 2D Ex ib IIIC T130°C Db / Ex ib IIIC T130°C Db
ATEX / IECEx Mining Rating
I M2 Ex ib I Mb / Ex ib I Mb
Maritime Certification
Marine Equipment Directive 2014/90/EU MED/5.20 and UK/5.20
ATEX / IECEx Ingress Protection (after thermal endurance & impact)
IP66 and IP68 (submersion up to 2 m for 2 hours) per IEC 60079 & IEC 60529
Military Standards MIL-STD 810
MIL-STD 810C/D/E/F/G/H
Chemical Resistance
Housing resistant to commercial disinfectants and decontamination substances
Operating Temperature with Battery
IIA Models: -25°C to +60°C (digital) / -20°C to +60°C (analogue) IIC Models: -30°C to +60°C
Storage Temperature
-40°C to +85°C
Electrostatic Discharge
IEC 61000-4-2 level 4
