Product ID: MXM600 (Databox)
The Motorola MXM600 Databox is a screenless TETRA mobile transceiver optimized for advanced data integration, M2M applications, and concealed installations. It features Class 2 (10 W) RF output power, dedicated RS232 and 25SubD interfaces, PEI multiplexing, AI noise suppression, Wi-Fi, Bluetooth 5.3, multi-GNSS, and IP54 environmental ruggedness.
Product features:
TETRA – screenless 10 W (Class 2) unit supporting DMO Repeater/Gateway and DIMETRA Connect Wi-Fi fallback
RS232 (9-pin SubD) and 25-pin SubD ports for direct M2M and telemetry device connectivity
Wi-Fi OTAP updates with full management via Virtual Control Head or Android app
Built-in Bluetooth 5.3, GNSS (GPS/Galileo/GLONASS/BeiDou), and certified IP54 / EN 50155 ruggedness • Product description
The Motorola MXM600 Databox is specifically designed for systems requiring reliable data transmission, machine-to-machine (M2M) communication, and covert vehicular installations. By eliminating the physical control head, the compact Databox transceiver saves space and allows easy mounting in equipment racks, under seats, or in vehicle trunks. Users can manage the unit remotely using a Virtual Control Head or via the collaborative M-Radio Control Android app.
Featuring the most comprehensive set of physical ports in the MXM600 series, the Databox includes a dedicated 9-pin SubD RS232 port and a 25-pin SubD connector. These interfaces enable direct connections to mobile data computers, telemetry equipment, and Peripheral Equipment Interfaces (PEI). Its Class 2 (10 W) RF transmitter combined with an external antenna ensures reliable SDS messaging and packet data transmission from areas with weak TETRA reception.
The Motorola MXM600 Databox features automated codeplug detection and control head alignment, streamlining multi-vehicle installations. Integrated Wi-Fi allows radio administrators to execute over-the-air programming (OTAP) and firmware updates whenever the vehicle enters a designated depot Wi-Fi zone. Full compatibility with MTM5000 series cabling and CPS/ITM software tools dramatically lowers total cost of ownership (TCO).
Intended Use and Application
The Motorola MXM600 Databox is tailored for on-board data systems, railways, telemetry stations, covert vehicles, and automated M2M infrastructure.
Railways & public transit: on-board data hub for passenger information, CAD/AVL integration, and telemetry (EN 50155 certified).
Covert & unmarked vehicles: concealed mounting controlled via Virtual Control Head software or Bluetooth smartphone app.
SCADA & critical infrastructure: reliable SDS and Multi-Slot Packet Data reporting from remote utility substations.
• Specification
Display / Keypad
None (Databox transceiver unit); controlled via Virtual Control Head, optional single RJ50 remote head, or M-Radio Control app
Talkgroup & Message Capacity
TMO: up to 10,000 (500 folders) / DMO: up to 2,000 (128 folders) / SDS Inbox/Outbox management
Databox Transceiver Dimensions (H x W x D)
45 x 172 x 192 mm
Total Weight (Transceiver + Expansion Head)
1450 g
Electrical Power Supply
10.8 V to 15.6 V DC (Current drain: Standby 0.5 A / Rx 1.1 A / Tx @ 10 W: 2.4 A, 3.5 A peak)
Wi-Fi Connectivity
IEEE 802.11a/b/g/n/ac (2.4 GHz, 5 GHz) supporting WPA2, WPA3 Enterprise, and TLS 1.2
Bluetooth Module
Version 5.3 (Class 1, line-of-sight range up to 90 m, AES128 NIST encryption)
GNSS Receiver
GPS, Galileo, GLONASS, BeiDou, QZSS (2D accuracy < 1.0 m for GPS+Galileo)
Physical Ports
1 x RS232 Port (9-pin SubD) for PEI and external PC data integration 1 x Multi-purpose 25-pin SubD connector (front/rear) for MTM5000 cabling compatibility 1 x RJ50 Ethernet Control Head connector 1 x 26-pin Rear Accessory connector with USB 2.0 / USB OTG capability
Data Speeds
Multi-Slot Packet Data (up to 4 slots, supporting up to 28.8 kbit/s), SDS concatenation up to 1000 characters
PEI & AT Multiplexer
TNP1 (simultaneous Packet Data and SDS), full ETSI/Enhanced AT command set, 4 virtual physical AT multiplexer ports
Frequency Bands
Wideband: 350–470 MHz or 806–870 MHz
RF Transmit Power Class
Class 2 (10 W) and Class 3 (3 W) with adaptive power control (15 dBm to 40 dBm)
Receiver Static Sensitivity (ETSI 300-392-2)
350–470 MHz: -116 dBm (guaranteed) / -118 dBm (typical) 806–870 MHz: -114 dBm (guaranteed) / -116 dBm (typical)
Receiver Dynamic Sensitivity (ETSI 300-392-2)
350–470 MHz: -107 dBm (guaranteed) / -109 dBm (typical) 806–870 MHz: -105 dBm (guaranteed) / -107 dBm (typical)
Repeater & Gateway Capability
DMO Repeater (ETSI Type 1A) and DMO/TMO Gateway functionality
Audio Output Power
External Loudspeakers: 7.5 W / 13 W / 15.6 W wideband
Noise Suppression
AI-trained Noise Suppression with Echo Cancellation and Howling Suppression
Air Interface Encryption
TEA1, TEA2, TEA3 (Classes 1, 2, 3, 3G) and hardware-ready for TEA5, TEA6, TEA7
End-to-End Encryption (E2EE)
AES128 or AES256 for voice and data via HSM card or internal TETRA / BSI SIM card
Military Standards MIL-STD
MIL-STD 810C/D/E/F/G/H
Industry & Railway Standards
RED 2014/53/EU, E-Mark (ECE Reg 10), EN 50155 / IEC 60571, EN 50121-3-2
Ingress Protection (dust and water)
IEC 60529: IP54 for the entire transceiver unit (including connected cables)
Operating Temperature
-30°C to +70°C (full performance -30°C to +60°C)
Storage Temperature
-40°C to +85°C
